WISENET SPE-1610
Details
Details
The SPE-1610 is a 16-channel encoder, with dual codec supporting H.264/MJPEG, at 30fps @ 2MP or lower and 15 fps @ 4MP. Compatible with AHD/CVI/TVI/CVBS video formats. Supports RS-485/422 Interface, Pelco C when using CVBS or ACP up-coax protocol @ AHD, ONVIF protocol support, HDMI output, I/O 16/4, Audio in/out 4/1, 12VDC. Supports ECO. Stream. bandwidth reduction technology (Firmware v1.04b /v1.30+ only).
- Supports AHD, CVI, TVI, & CVBS video formats
- Supports ACP/Pelco-C up-the-coax & RS-485/422 PTZ control interface
- Motion detection, Video loss, Tampering
- H.264, MJPEG codec support
- ECO. Stream. bandwidth reduction technology per channel/profile (firmware v1.04b_200227 / v1.30+ only)
- Multiple streaming (Up to 3 profiles per channel)
- HDMI Output
- Alarm & Audio I/O
Technical Specification
Technical Specification
Ports | 16 |
Form Factor | Encoder |
Vendors Part Number | SPE-1610 |
